9×53mmR

Introduced 1955M. N. BlumCIP standard

Dimensions and pressure

Generated from the schema, like every specification table on this site, so a figure recorded on this entry cannot be missing from the table.

Identity
Designed by
M. N. Blum
Introduced
1955
Production
not recorded
Standards body
C.I.P.
Case type
Rimmed
Case shape
Bottleneck
Dimensions
Bullet diameter
9.27 mm0.3650 insource

Dimension G1.

Bore diameter
not recorded
Case length
53 mm2.087 insource

Cartridge maximum, dimension L3.

Overall length
67 mm2.638 insource

Dimension L6.

Rim diameter
14.48 mm0.5701 insource

Dimension R1.

Neck diameter
9.86 mm0.3882 insource

Dimension H2.

Base diameter
12.42 mm0.4890 insource

Dimension P1.

Pressure
Maximum pressure
340 MPa49,313 psisource

Pmax 3400 bar, C.I.P. method. Wikipedia's infobox cites a Russian source (lveplant.ru) giving a substantially lower 254.8 MPa; this page follows the C.I.P. standards-body figure.

Pressure standard
C.I.P.

SAAMI and C.I.P. measure pressure differently and their figures are not interchangeable, which is why the body is always named beside the figure.

Loads

Velocity is recorded per barrel length as published. A gun page interpolates between these points and never projects beyond them.

15 g LVE

Bullet mass
15 g231.5 grestimated

Wikipedia infobox, citing a Russian ammunition-industry source (lveplant.ru). No test-barrel length is stated for the load's published velocity, so velocity is not recorded.

Cartridge mass
not recorded
Bullet type
LVE
G1 BC
not recorded
G7 BC
not recorded

Chambered in

Computed from every entry that lists this cartridge. Nothing here is hand-maintained.

No entry on the site is chambered in it yet.

Detail

The 9×53mmR is a rimmed, bottlenecked rifle cartridge M. N. Blum designed in 1955 by necking up the Soviet 7.62×54mmR service case to take a much larger, 9.27 mm bullet. It was built as a civilian hunting round rather than a military one, drawing on a rimmed case already produced at scale for the Mosin–Nagant family of rifles and machine guns.

Production began in 1962 and continued, with a gap from 1992 to 1997, into the post-Soviet Russian ammunition industry. Since 1971 the round has been loaded in two standard bullet types for different game classes: a soft-point load for larger animals and a full-metal-jacket load for smaller ones. Several Soviet- and Russian-made hunting rifles have been chambered for it, including bolt-action carbines and, more recently, semi-automatic designs derived from the Saiga rifle family.

Case and diameter dimensions on this page come from C.I.P.’s published standard and are recorded as verified. C.I.P.’s stated maximum pressure of 340 MPa is markedly higher than the 254.8 MPa figure Wikipedia’s infobox cites from a Russian ammunition-industry source; this page follows the C.I.P. standards-body figure as verified and notes the disagreement here rather than picking a value to call correct. A single bullet weight is recorded from the same Russian source, but no test-barrel length is stated for its published velocity, so no velocity or energy figure is recorded for this cartridge. No photograph of a rifle chambered for it appears on this site.

References

  1. 9×53mmR · 1371908744 · read 2026-09-24
  2. C.I.P. TDCC datasheet — 9 x 53 R · 1999-03-23 · read 2026-09-24
