7.62×53mmR

Introduced 1918Finnish state arsenalsCIP standard

Dimensions and pressure

Generated from the schema, like every specification table on this site, so a figure recorded on this entry cannot be missing from the table.

Identity
Designed by
Finnish state arsenals
Introduced
1918
Production
not recorded
Standards body
C.I.P.
Case type
Rimmed
Case shape
Bottleneck
Dimensions
Bullet diameter
7.85 mm0.3091 insource

C.I.P. G1, maximum bullet diameter.

Bore diameter
not recorded
Case length
53.5 mm2.106 insource

C.I.P. L3, maximum case length.

Overall length
77 mm3.031 insource

C.I.P. L6, maximum cartridge overall length.

Rim diameter
14.4 mm0.5669 insource

C.I.P. R1.

Neck diameter
8.5 mm0.3346 insource

C.I.P. H2.

Base diameter
12.42 mm0.4890 insource

C.I.P. P1.

Pressure
Maximum pressure
390 MPa56,565 psisource

C.I.P. Pmax 3900 bar; 1 bar = 0.1 MPa exactly.

Pressure standard
C.I.P.

SAAMI and C.I.P. measure pressure differently and their figures are not interchangeable, which is why the body is always named beside the figure.

Loads

Velocity is recorded per barrel length as published. A gun page interpolates between these points and never projects beyond them.

185.4 gr full metal jacket ball

Finnish state arsenals

Bullet mass
12.02 g185.5 grestimatedsource

Cited article's ballistics table publishes 185.4 grains; converted here. No barrel length is stated anywhere in the article, so no velocity is recorded for this load.

Cartridge mass
not recorded
Bullet type
FMJ
G1 BC
not recorded
G7 BC
not recorded

Chambered in

Computed from every entry that lists this cartridge. Nothing here is hand-maintained.

No entry on the site is chambered in it yet.

Detail

The 7.62×53mmR is a rimmed, bottlenecked rifle cartridge adopted by Finland in 1918, developed from the Russian 7.62×54mmR that the newly independent country inherited in Mosin–Nagant rifles left over from Imperial Russian service. It remains Finland’s standard rifle and machine-gun cartridge for the arms still in reserve or ceremonial use, chambered in the Finnish-built m/28, m/28-30 and m/39 Mosin–Nagant variants and the Lahti-Saloranta M/26 light machine gun.

This is a distinct cartridge from the 7.62×54mmR it descends from, not an alternate name for it. The two share a rim diameter and are near-interchangeable in the chamber, but Finnish production held its own dimensional standard, separately registered with C.I.P., with a case length of 53.5 mm against the Russian round’s 53.72 mm and its own maximum pressure of 390 MPa — tighter, domestically produced tolerances that Finnish shooters and collectors still distinguish from wartime and Soviet-era 54mmR ammunition.

This entry carries the full C.I.P. dimensional standard, verified against the published datasheet. One ball load’s bullet mass, converted from a published 185.4 grains, is recorded as estimated because the source Wikipedia table does not credit a factory sheet. No test barrel length is stated anywhere in the cited article, so no velocity is recorded and the cartridge computes no muzzle energy or trajectory; no ballistic coefficient is published for it free either.

References

  1. 7.62×53mmR · 1337027079 · read 2026-09-01
  2. C.I.P. TDCC datasheet — 7,62 x 53 R · 2002-05-15 · read 2026-09-01

Last verified 2026-09-01 · review status: agent-populated
