The Chevrolet bowtie emblem, a stylised horizontal cross shape

Generation

Chevrolet Camaro (first generation)

Chevrolet Camaro (first generation), 1966-1969

Produced
1966–1969
Code
F-body (1st gen)
Designer
Henry Haga
Orange 1969 Chevrolet Camaro SS 396 photographed from the front three-quarter angle at a car show, showing its black bonnet stripes and SS badging

Image credit

File
File:1969 red Chevrolet Camaro SS side.JPG
Author (attribution required)
BrokenSphere

Powertrain

Introduced in September 1966 for the 1967 model year, the first Camaro shared its F-body platform with the Pontiac Firebird and its subframe design with the contemporary Chevy II Nova.[1] Twelve different engines were available by 1969, from the standard 230-cubic-inch straight-six up to a 427-cubic-inch COPO big-block Chevrolet never officially listed in sales literature; the RS, SS and Z/28 option packages did the work of turning the same basic car into anything from a boulevard cruiser to a Trans-Am homologation special.

The Z/28’s advertised 290 hp was, by Chevrolet’s own later admission, deliberately understated to keep the car under an informal one-horsepower- per-cubic-inch limit insurers and racing bodies used for classification. This is a case where the “official” figure is known to undersell the engine, recorded here as the manufacturer’s published rating rather than corrected upward.

Overview

Manufacturer
Chevrolet
Produced
1966–1969
Model code
F-body (1st gen)
Designer
Henry Haga
Segment
S-segment (Europe) / Sports car (US)
Positioning
Mainstream
Assembly
  • Chevrolet, Van Nuys, California, United States
  • Chevrolet, Norwood, Ohio, United States

Dimensions

Length
4,691 mm

184.7 in (MY1967-68), converted at 25.4 mm/in. MY1969 grew to 186.0 in (4,724 mm).

[1]

Width
Not yet available
Height
Not yet available
Wheelbase
2,743 mm

108 in, converted at 25.4 mm/in.

[1]

Kerb weight
Not yet available

230 Turbo-Thrift I6

Trim · 1966–1969 · Turbo-Thrift

Power
104 kW

140 hp (SAE gross) at 4,400 rpm, converted at 1 hp = 0.74569987 kW. The standard engine at launch.

[1]

Torque
298 N⋅m

220 lb-ft at 1,600 rpm, converted at 1.35581795 Nm/lb-ft.

[1]

Kerb weight
Not yet available
0–100 km/h
Not yet available
Top speed
Not yet available
Fuel economy
Not yet available
CO₂
Not yet available
Drag coefficient
Not yet available
Frontal area
Not yet available
Displacement
3,769 cc

230 cubic inches, converted at 16.387064 cc/cu in.

[1]

Boot volume
Not yet available
Seats
4
Engine
inline-6 · Turbo-Thrift
Drivetrain
Rear-wheel drive

SS 396 (L78)

Trim · 1967–1969 · L78

Power
280 kW

375 bhp (SAE gross) at 5,600 rpm, the higher-output of two 396 SS tunes (325 or 375 bhp), converted at 1 hp = 0.74569987 kW.

[1]

Torque
563 N⋅m

415 lb-ft at 3,600 rpm, converted at 1.35581795 Nm/lb-ft.

[1]

Kerb weight
Not yet available
0–100 km/h
Not yet available
Top speed
Not yet available
Fuel economy
Not yet available
CO₂
Not yet available
Drag coefficient
Not yet available
Frontal area
Not yet available
Displacement
6,489 cc

396 cubic inches, converted at 16.387064 cc/cu in.

[1]

Boot volume
Not yet available
Seats
4
Engine
V8, big-block · L78
Drivetrain
Rear-wheel drive

Sources & confidence

Every figure above carries a status. Nothing on this page is estimated without saying so, and nothing missing has been filled in with a guess.

Last verified
2026-09-24
Review status
Compiled from cited sources

Photography on this page is credited on each image. Tap theion a photograph for its author, licence and source.

References

Every sourced figure and every cited claim on this page, numbered. Wikipedia articles record the revision they were read at, because the article will have changed by the time you check it.

  1. [1]

    Chevrolet Camaro (first generation). Wikipedia · revision 1370188693 · read 2026-09-24

    WikipediaCC BY-SA 4.0
