Toyota emblem

Generation

Toyota Hilux (N10)

Toyota Hilux (N10), 1968-1972

Produced
1968–1972
Code
N10
Designer
Takayuki Otsuka
Light blue original Toyota Hilux N10 pickup truck photographed from the front three-quarter angle

Image credit

File
File:Toyota N10 1600 Pick-up (1974) 02 (cropped).jpg
Author (attribution required)
Andrew Bone
Licence
CC BY 4.0

Body style

Powertrain

The N10 was engineered and built by Hino Motors, not Toyota’s own factories, to replace the smaller Hino-derived Briska.[1] US-bound trucks were shipped as a bare chassis cab and had their beds built and fitted locally in Long Beach. This was a deliberate piece of tariff engineering to reduce the 25% “chicken tax” on imported light trucks to a 4% rate on chassis alone.

The wheelbase field on this entry is a genuine data problem in the source rather than a conversion trap. The article’s own infobox states the short-wheelbase figure as 4,215 mm, identical to its own separately stated overall length for the same body, which cannot be correct, since a vehicle’s wheelbase is always shorter than its overall length. The long-wheelbase figure given alongside it, 2,785 mm, is shorter still, confirming something is transposed or mislabelled in the source. Rather than guess which number belongs where, this entry records the wheelbase as conflicting-sources with a null value.

Overview

Manufacturer
Toyota
Produced
1968–1972
Model code
N10
Designer
Takayuki Otsuka
Segment
Pickup (Europe) / Pickup truck (US)
Positioning
Economy
Assembly
  • Hamura, Tokyo, Japan (Hino Motors)
  • Long Beach, California, US (Atlas Fabricators, final assembly, 1971-1972)
  • Durban, South Africa (Motor Assemblies Ltd., from 1969)
  • Montevideo, Uruguay (Ayax S.A., from 1971)

Dimensions

Length
4,215 mm

Short-wheelbase truck. Long-wheelbase variants ranged up to 4,665 mm (box van).

[1]

Width
1,580 mm

[1]

Height
1,575 mm

Standard truck. The box van variant is 1,830 mm.

[1]

Wheelbase
Not yet available

The infobox states the short-wheelbase figure as 4,215 mm, identical to its own length figure for the same body. This is almost certainly a transcription error in the source (a wheelbase cannot equal a vehicle's overall length). The long-wheelbase figure of 2,785 mm is given separately and is itself shorter than this "short" wheelbase figure, which confirms the two values are swapped or mislabelled in the article. Left as `null` rather than guessing which of the two numbers is correct, since that would be inventing data.

Kerb weight
1,025 kg

Low end of the 1,025-1,040 kg short-wheelbase truck range.

[1]

1.5 (2R)

Trim · 1968–1971 · 2R

Power
51 kW

Low end of a published 70-77 PS range, converted at 1 PS = 0.73549875 kW.

[1]

Torque
Not yet available
Kerb weight
1,025 kg

Low end of the short-wheelbase truck weight range.

[1]

0–100 km/h
Not yet available
Top speed
Not yet available
Fuel economy
Not yet available
CO₂
Not yet available
Drag coefficient
Not yet available
Frontal area
Not yet available
Displacement
1,490 cc

[1]

Boot volume
Not yet available
Seats
2
Engine
inline-4, OHV · 2R
Drivetrain
Rear-wheel drive

1.6 (12R)

Trim · 1971–1972 · 12R

Power
61 kW

Low end of a published 83-91 PS range, converted at 1 PS = 0.73549875 kW.

[1]

Torque
Not yet available
Kerb weight
1,040 kg

High end of the short-wheelbase truck weight range.

[1]

0–100 km/h
Not yet available
Top speed
Not yet available
Fuel economy
Not yet available
CO₂
Not yet available
Drag coefficient
Not yet available
Frontal area
Not yet available
Displacement
1,587 cc

[1]

Boot volume
Not yet available
Seats
2
Engine
inline-4, OHV · 12R
Drivetrain
Rear-wheel drive

Sources & confidence

Every figure above carries a status. Nothing on this page is estimated without saying so, and nothing missing has been filled in with a guess.

Last verified
2026-09-08
Review status
Compiled from cited sources

Photography on this page is credited on each image. Tap theion a photograph for its author, licence and source.

References

Every sourced figure and every cited claim on this page, numbered. Wikipedia articles record the revision they were read at, because the article will have changed by the time you check it.

  1. [1]

    Toyota Hilux. Wikipedia · revision 1373684850 · read 2026-09-08

    WikipediaCC BY-SA 4.0

    Covers all eight Hilux generations in one article, with per-generation infoboxes and engine tables.
